Q-Pumps QIM Series In-Line Shear Mixing Pumps

Perfectly created solutions for applications that require to be homogenized or disintegrated while being pumped. Centrifugal equipment in radial flow line designed under 3-A & EHEDG standards.


QIM Series In-Line Shear Mixing Pumps

Q-Pumps

Characteristics

  • Has a semi-open impeller design to keep pressurized and achieve better lubrication in the mechanical seal.

  • Built in SS 316L with surface finish on all surfaces in contact with the fluid 32 Ra maximum

  • Completely drainable with the discharge in horizontal position

  • Use of o-ring to achieve a better seal

  • Easy maintenance and high efficiency

  • 5 different backplates options for better performance

  • Designed under 3-A and EHEDG standards

Backplate Options:

- Big Slots: For disintegrations of hard solids.

- Big Inclined Slots: For disintegration of small solids.

- Big Radial Slots: For mixing powders and liquids.

- Small Slots: For disintegrations of soft solids.

- Small Radial Slots: For emulsifying different liquids.

 Advantages

  • Thanks to its modular design, QIM Inline Mixers can be converted into a QDB Dry Blender by adding a table and a cone

  • It’s different backplate options makes the QIM tailor-made for each application

  • A QC+ can be converted into a QIM

Manufacturer
:
Q-Pumps

QIM Series In-Line Shear Mixing Pumps (QIM_Series_In-Line_Shear_Mixing_Pumps.pdf, 1,708 Kb) [Download]
